Perforated Roller Shutter

request-a-quoteBHP Galvabond G2 Z275 steel in 1.0mm gauge slats.
SOUND AND SECURE
Roller Shutters are a proven versatile style of door, ideal for non-cyclonic areas. They are available with smooth manual or power operation in the full colour range of powder coated 2 finishes. They can be sized to suit openings up to a large 36m .

Roller shutters are ideal for both external and internal installations in most building projects
including warehouses, factories, shopping centres, recreation and sporting centres, mining
and heavy industry workshop facilities.

DOOR CURTAIN ASSEMBLY
105mm slat profile (Galvabond- 1.0mm or 1.2mm-G2-Z275) with Windlocked Nylon clip which secures curtain into guides.

HEAVY DUTY GUIDE ASSEMBLY
90mm deep with wall thickness of 2.95mm and formed lock rail running full length of guide to secure wind lock clips.

DRUM ASSEMBLY
The drum is manufactured from mild steel tube. The drum houses bearings counter balancing helical torsion springs, capable of producing sufficient torque to ensure ease of operation of the curtain from any position. With 1.0mm or 1.2mm steel slats with cast windlock clips every slat. Optional powder coat colours. AS/NZS 1170.2 - 2002. With patent pending (AU2012261562)
Cyclonic guide clamps
All torsion spring used are coiled and heat treated to AS for performance and durability.
All drum and axle components are fabricated using high quality carbon steel.

BOTTOM RAIL ASSEMBLY
Aluminium T/Bar with bottom weather seal.

MOTOR OR MANUAL
Motor operation is a 1hp, 3 phase, Grifco operator
